I Finally Found a Solid Debian Tablet: The Surface Go 2

I have been looking for a good tablet for Debian for… well, years. I want thin, light, portable, excellent battery life, and a servicable keyboard.

For a while, I tried a Lenovo Chromebook Duet. It meets the hardware requirements, well sort of. The problem is with performance and the OS. I can run Debian inside the ChromeOS Linux environment. That works, actually pretty well. But it is slow. Terribly, terribly, terribly slow. Emacs takes minutes to launch. apt-gets also do. It has barely enough RAM to keep its Chrome foundation happy, let alone a Linux environment also. But basically it is too slow to be servicable. Not just that, but I ran into assorted issues with having it tied to a Google account – particularly being unable to login unless I had Internet access after an update. That and my growing concern over Google’s privacy practices led me sort of write it off.

I have a wonderful System76 Lemur Pro that I’m very happy with. Plenty of RAM, a good compromise size between portability and screen size at 14.1″, and so forth. But a 10″ goes-anywhere it’s not.

I spent quite a lot of time looking at thin-and-light convertible laptops of various configurations. Many of them were quite expensive, not as small as I wanted, or had dubious Linux support. To my surprise, I wound up buying a Surface Go 2 from the Microsoft store, along with the Type Cover. They had a pretty good deal on it since the Surface Go 3 is out; the highest-processor model of the Go 2 is roughly similar to the Go 3 in terms of performance.

There is an excellent linux-surface project out there that provides very good support for most Surface devices, including the Go 2 and 3.

I put Debian on it. I had a fair bit of hassle with EFI, and wound up putting rEFInd on it, which mostly solved those problems. (I did keep a Windows partition, and if it comes up for some reason, the easiest way to get it back to Debian is to use the Windows settings tool to reboot into advanced mode, and then select the appropriate EFI entry to boot from there.)

Researching on-screen keyboards, it seemed like Gnome had the most mature. So I wound up with Gnome (my other systems are using KDE with tiling, but I figured I’d try Gnome on it.) Almost everything worked without additional tweaking, the one exception being the cameras. The cameras on the Surfaces are a known point of trouble and I didn’t bother to go to all the effort to get them working.

With 8GB of RAM, I didn’t put ZFS on it like I do on other systems. Performance is quite satisfactory, including for Rust development. Battery life runs about 10 hours with light use; less when running a lot of cargo builds, of course.

The 1920×1280 screen is nice at 10.5″. Gnome with Wayland does a decent job of adjusting to this hi-res configuration.

I took this as my only computer for a trip from the USA to Germany. It was a little small at times; though that was to be expected. It let me take a nicely small bag as a carryon, and being light, it was pleasant to carry around in airports. It served its purpose quite well.

One downside is that it can’t be powered by a phone charger like my Chromebook Duet can. However, I found a nice slim 65W Anker charger that could charge it and phones simultaneously that did the job well enough (I left the Microsoft charger with the proprietary connector at home).

The Surface Go 2 maxes out at a 128GB SSD. That feels a bit constraining, especially since I kept Windows around. However, it also has a micro SD slot, so you can put LUKS and ext4 on that and use it as another filesystem. I popped a micro SD I had lying around into there and that felt a lot better storage-wise. I could also completely zap Windows, but that would leave no way to get firmware updates and I didn’t really want to do that. Still, I don’t use Windows and that could be an option also.

All in all, I’m pretty pleased with it. Around $600 for a fully-functional Debian tablet, with a keyboard is pretty nice.

I had been hoping for months that the Pinetab would come back into stock, because I’d much rather support a Linux hardware vendor, but for now I think the Surface Go series is the most solid option for a Linux tablet.

Pipe Issue Likely a Kernel Bug

Saturday, I wrote in Pipes, deadlocks, and strace annoyingly fixing them about an issue where a certain pipeline seems to have a deadlock. I described tracing it into kernel code. Indeed, it appears to be kernel bug 212295, which has had a patch for over a year that has never been merged.

After continuing to dig into the issue, I eventually reported it as a bug in ZFS. One of the ZFS people connected this to an older issue my searching hadn’t uncovered.

rincebrain summarized:

I believe, if I understand the bug correctly, it only triggers if you F_SETPIPE_SZ when the writer has put nonzero but not a full unit’s worth in yet, which is why the world isn’t on fire screaming about this – you need to either have a very slow but nonzero or otherwise very strange write pattern to hit it, which is why it doesn’t come up in, say, the CI or most of my testbeds, but my poor little SPARC (440 MHz, 1c1t) and Raspberry Pis were not so fortunate.

You might recall in Saturday’s post that I explained that Filespooler reads a few bytes from the gpg/zstdcat pipeline before spawning and connecting it to zfs receive. I think this is the critical piece of the puzzle; it makes it much more likely to encounter the kernel bug. zfs receive is calls F_SETPIPE_SZ when it starts. Let’s look at how this could be triggered:

In the pre-Filespooler days, the gpg|zstdcat|zfs pipeline was all being set up at once. There would be no data sent to zfs receive until gpg had initialized and begun to decrypt the data, and then zstdcat had begun to decompress it. Those things almost certainly took longer than zfs receive’s initialization, meaning that usually F_SETPIPE_SZ would have been invoked before any data entered the pipe.

After switching to Filespooler, the particular situation here has Filespooler reading somewhere around 100 bytes from the gpg|zstdcat part of the pipeline before ever invoking zfs receive. zstdcat generally emits more than 100 bytes at a time. Therefore, when Filespooler invokes zfs receive and hooks the pipeline up to it, it has a very high chance of there already being data in the pipeline when zfs receive uses F_SETPIPE_SZ. This means that the chances of encountering the conditions that trigger the particular kernel bug are also elevated.

ZFS is integrating a patch to no longer use F_SETPIPE_SZ in zfs receive. I have applied that on my local end to see what happens, and hopefully in a day or two will know for sure if it resolves things.

In the meantime, I hope you enjoyed this little exploration. It resulted in a new bug report to Rust as well as digging up an existing kernel bug. And, interestingly, no bugs in filespooler. Sometimes the thing that changed isn’t the source of the bug!

Pipes, deadlocks, and strace annoyingly fixing them

This is a complex tale I will attempt to make simple(ish). I’ve (re)learned more than I cared to about the details of pipes, signals, and certain system calls – and the solution is still elusive.

For some time now, I have been using NNCP to back up my files. These backups are sent to my backup system, which effectively does this to process them (each ZFS send is piped to a shell script that winds up running this):

gpg -q -d | zstdcat -T0 | zfs receive -u -o readonly=on "$STORE/$DEST"

This processes tens of thousands of zfs sends per week. Recently, having written Filespooler, I switched to sending the backups using Filespooler over NNCP. Now fspl (the Filespooler executable) opens the file for each stream and then connects it to what amounts to this pipeline:

bash -c 'gpg -q -d 2>/dev/null | zstdcat -T0' | zfs receive -u -o readonly=on "$STORE/$DEST"

Actually, to be more precise, it spins up the bash part of it, reads a few bytes from it, and then connects it to the zfs receive.

And this works well — almost always. In something like 1/1000 of the cases, it deadlocks, and I still don’t know why. But I can talk about the journey of trying to figure it out (and maybe some of you will have some ideas).

Filespooler is written in Rust, and uses Rust’s Command system. Effectively what happens is this:

  1. The fspl process has a File handle, which after forking but before invoking bash, it dup2’s to stdin.
  2. The connection between bash and zfs receive is a standard Unix pipe.

I cannot get the problem to duplicate when I run the entire thing under strace -f. So I am left trying to peek at it from the outside. What happens if I try to attach to each component with strace -p?

  • bash is blocking in wait4(), which is expected.
  • gpg is blocking in write().
  • If I attach to zstdcat with strace -p, then all of a sudden the deadlock is cleared and everything resumes and completes normally.
  • Attaching to zfs receive with strace -p causes no output at all from strace for a few seconds, then zfs just writes “cannot receive incremental stream: incomplete stream” and exits with error code 1.

So the plot thickens! Why would connecting to zstdcat and zfs receive cause them to actually change behavior? strace works by using the ptrace system call, and ptrace in a number of cases requires sending SIGSTOP to a process. In a complicated set of circumstances, a system call may return EINTR when a SIGSTOP is received, with the idea that the system call should be retried. I can’t see, from either zstdcat or zfs, if this is happening, though.

So I thought, “how about having Filespooler manually copy data from bash to zfs receive in a read/write loop instead of having them connected directly via a pipe?” That is, there would be two pipes going there: one where Filespooler reads from the bash command, and one where it writes to zfs. If nothing else, I could instrument it with debugging.

And so I did, and I found that when it deadlocked, it was deadlocking on write — but with no discernible pattern as to where or when. So I went back to directly connected.

In analyzing straces, I found a Rust bug which I reported in which it is failing to close the read end of a pipe in the parent post-fork. However, having implemented a workaround for this, it doesn’t prevent the deadlock so this is orthogonal to the issue at hand.

Among the two strange things here are things returning to normal when I attach strace to zstdcat, and things crashing when I attach strace to zfs. I decided to investigate the latter.

It turns out that the ZFS code that is reading from stdin during zfs receive is in the kernel module, not userland. Here is the part that is triggering the “imcomplete stream” error:

                int err = zfs_file_read(fp, (char *)buf + done,
                    len - done, &resid);
                if (resid == len - done) {
                        /*
                         * Note: ECKSUM or ZFS_ERR_STREAM_TRUNCATED indicates
                         * that the receive was interrupted and can
                         * potentially be resumed.
                         */
                        err = SET_ERROR(ZFS_ERR_STREAM_TRUNCATED);
                }

resid is an output parameter with the number of bytes remaining from a short read, so in this case, if the read produced zero bytes, then it sets that error. What’s zfs_file_read then?

It boils down to a thin wrapper around kernel_read(). This winds up calling __kernel_read(), which calls read_iter on the pipe, which is pipe_read(). That’s where I don’t have the knowledge to get into the weeds right now.

So it seems likely to me that the problem has something to do with zfs receive. But, what, and why does it only not work in this one very specific situation, and only so rarely? And why does attaching strace to zstdcat make it all work again? I’m indeed puzzled!

Update 2022-06-20: See the followup post which identifies this as likely a kernel bug and explains why this particular use of Filespooler made it easier to trigger.

KDE: A Nice Tiling Envieonment and a Surprisingly Awesome DE

I recently wrote that managing an external display on Linux shouldn’t be this hard. I went down a path of trying out some different options before finally landing at an unexpected place: KDE. I say “unexpected” because I find tiling window managers are just about a necessity.

Background: xmonad

Until a few months ago, I’d been using xmonad for well over a decade. Configurable, minimal, and very nice; it suited me well.

However, xmonad is getting somewhat long in the tooth. xmobar, which is commonly used with it, barely supports many modern desktop environments. I prefer DEs for the useful integrations they bring: everything from handling mount of USB sticks to display auto-switching and sound switching. xmonad itself can’t run with modern Gnome (whether or not it runs well under KDE 5 seems to be a complicated question, according to wikis, but in any case, there is no log applet for KDE 5). So I was left with XFCE and such, but the isues I identified in the “shouldn’t be this hard” article were bad enough that I just could not keep going that way.

An attempt: Gnome and PaperWM

So I tried Gnome under Wayland, reasoning that Wayland might stand a chance of doing things well where X couldn’t. There are several tiling window extensions available for the Gnome 3 shell. Most seemed to be rather low-quality, but an exception was PaperWM and I eventually decided on it. I never quite decided if I liked its horizontal tape of windows or not; it certainly is unique in any case.

I was willing to tolerate my usual list of Gnome problems for the sake of things working. For instance:

  • The Windows-like “settings are spread out in three different programs and some of them require editing the registry[dconf]”. Finding all the options for keybindings and power settings was a real chore, but done.
  • Some file dialog boxes (such as with the screenshot-taking tool) just do not let me type in a path to save a file, insisting that I first navigate to a directory and then type in a name.
  • General lack of available settings or hiding settings from people.
  • True focus-follows-mouse was incompatible with keyboard window switching (PaperWM or no); with any focus-follows-mouse enabled, using Alt-Tab or any other method to switch to other windows would instantly have focus returned to whatever the mouse was over.

Under Wayland, I found a disturbing lack of logs. There was nothing like /var/log/Xorg.0.log, nothing like ~/.xsession-errors, just nothing. Searching for answers on this revealed a lot of Wayland people saying “it’s a Gnome issue” and the trail going cold at that point.

And there was a weird problem that I just could not solve. After the laptop was suspended and we-awakened, I would be at a lock screen. I could type in my password, but when hitting Enter, the thing would then tend to freeze. Why, I don’t know. It seemed related to Gnome shell; when I switched Gnome from Wayland to X11, it would freeze but eventually return to the unlock screen, at which point I’d type in my password and it would freeze again. I spent a long time tracking down logs to see what was happening, but I couldn’t figure it out. All those hard resets were getting annoying.

Enter KDE

So I tried KDE. I had seen mentions of kwin-tiling, a KDE extension for tiling windows. I thought I’d try this setup.

I was really impressed by KDE’s quality. Not only did it handle absolutely every display-related interaction correctly by default, with no hangs ever, all relevant settings were clearly presented in one place. The KDE settings screens were a breath of fresh air – lots of settings available, all at one place, and tons of features I hadn’t seen elsewhere.

Here are some of the things I was pleasantly surprised by with KDE:

  • Applications can declare classes of notifications. These can be managed Android-style in settings. Moreover, you can associate a shell command to run with a notification in any class. People use this to do things like run commands when a display locks and so forth.
  • KDE Connect is a seriously impressive piece of software. It integrates desktops with Android devices in a way that’s reminiscent of non-free operating systems – and with 100% Free Software (the phone app is even in F-Droid!). Notifications from the phone can appear on the desktop, and their state is synchronized; dismiss it on the desktop and it dismisses on the phone, too. Get a SMS or Signal message on the phone? You can reply directly from the desktop. Share files in both directions, mount a directory tree from the phone on the desktop, “find my phone”, use the phone as a presentation remote for the desktop, shared clipboard, sending links between devices, control the phone media player from the desktop… Really, really impressive.
  • The shortcut settings in KDE really work and are impressive. Unlike Gnome, if you try to assign the same shortcut to multiple things, you are warned and prevented from doing this. As with Gnome, you can also bind shorcuts to arbitrary actions.
  • This shouldn’t be exciting, but I was just using Gnome, so… The panel! I can put things wherever I want them! I can put it at the top of the screen, the bottom, or even the sides! It lets all my regular programs (eg, Nextcloud) put their icons up there without having to install two different extensions, each of which handles a different set of apps! I shouldn’t be excited about all this, because Gnome actually used to have these features years ago… [gripe gripe]
  • Initially I was annoyed that Firefox notifications weren’t showing up in the notification history as they did in Gnome… but that was, of course, a setting, easily fixed!
  • There is a Plasma Integration plugin for Firefox (and other browsers including Chrome). It integrates audio and video playback, download status, etc. with the rest of KDE and KDE Connect. Result: if you like, when a call comes in to your phone, Youtube is paused. Or, you can right-click to share a link to your phone via KDE Connect, and so forth. You can right click on a link, and share via Bluetooth, Nextcloud (it must have somehow registered with KDE), KDE Connect, email, etc.

Tiling

So how about the tiling system, kwin-tiling? The out of the box experience is pretty nice. There are fewer built-in layouts than with xmonad, but the ones that are there are doing a decent job for me, and in some cases are more configurable (those that have a large window pane are configurable on its location, not forcing it to be on the left as with many systems.) What’s more, thanks to the flexibility in the KDE shortcut settings, I can configure it to be nearly keystroke-identical to xmonad!

Issues Encountered

I encountered a few minor issues:

  • There appears to be no way to tell it to “power down the display immediately after it is locked, every time” instead of waiting for some timeout to elapse. This is useful when I want to switch monitor inputs to something else.
  • Firefox ESR seems to have some rendering issues under KDE for some reason, but switching to the latest stable release direct from Mozilla seems to fix that.

In short, I’m very impressed.

Managing an External Display on Linux Shouldn’t Be This Hard

I first started using Linux and FreeBSD on laptops in the late 1990s. Back then, there were all sorts of hassles and problems, from hangs on suspend to pure failure to boot. I still worry a bit about suspend on unknown hardware, but by and large, the picture of Linux on laptops has dramatically improved over the last years. So much so that now I can complain about what would once have been a minor nit: dealing with external monitors.

I have a USB-C dock that provides both power and a Thunderbolt display output over the single cable to the laptop. I think I am similar to most people in wanting the following behavior from the laptop:

  • When the lid is closed, suspend if no external monitor is connected. If an external monitor is connected, shut off the built-in display and use the external one exclusively, but do not suspend.
  • Lock the screen automatically after a period of inactivity.
  • While locked, all connected displays should be powered down.
  • When an external display is connected, begin using it automatically.
  • When an external display is disconnected, stop using it. If the lid is closed when the external display is disconnected, go into suspend mode.

This sounds so simple. But somehow on Linux we’ve split up these things into a dozen tiny bits:

  • In /etc/systemd/logind.conf, there are settings about what to do when the lid is opened or closed.
  • Various desktop environments have overlapping settings covering the same things.
  • Then there are the display managers (gdm3, lightdm, etc) that also get in on the act, and frequently have DIFFERENT settings, set in different places, from the desktop environments. And, what’s more, they tend to be involved with locking these days.
  • Then there are screensavers (gnome-screensaver, xscreensaver, etc.) that also enter the picture, and also have settings in these areas.

Problems I’ve Seen

My problems don’t even begin with laptops, but with my desktop, running XFCE with xmonad and lightdm. My desktop is hooked to a display that has multiple inputs. This scenario (reproducible in both buster and bullseye) causes the display to be unusable until a reboot on the desktop:

  1. Be logged in and using the desktop
  2. Without locking the desktop screen, switch the display input to another device
  3. Keep the display input on another device long enough for the desktop screen to auto-lock
  4. At this point, it is impossible to re-awaken the desktop screen.

I should not here that the problems aren’t limited to Debian, but also extend to Ubuntu and various hardware.

Lightdm: which greeter?

At some point while troubleshooting things after upgrading my laptop to bullseye, I noticed that while both were running lightdm, I had different settings and a different appearance between the two. Upon further investigation, I realized that one hat slick-greeter and lightdm-settings installed, while the other had lightdm-gtk-greeter and lightdm-gtk-greeter-settings installed. Very strange.

XFCE: giving up

I eventually gave up on making lightdm work. No combination of settings or greeters would make things work reliably when changing screen configurations. I installed xscreensaver. It doesn’t hang, but it does sometimes take a few tries before it figures out what device to display on.

Worse, since updating from buster to bullseye, XFCE no longer automatically switches audio output when the docking station is plugged in, and there seems to be no easy way to convince Pulseaudio to do this.

X-Based Gnome and derivatives… sigh.

I also tried Gnome, Mate, and Cinnamon, and all of them had various inabilities to configure things to act the way I laid out above.

I’ve long not been a fan of Gnome’s way of hiding things from the user. It now has a Windows-like situation of three distinct settings programs (settings, tweaks, and dconf editor), which overlap in strange ways and interact with systemd in even stranger ways. Gnome 3 make it quite non-intuitive to make app icons from various programs work, and so forth.

Trying Wayland

I recently decided to set up an older laptop that I hadn’t used in awhile. After reading up on Wayland, I decided to try Gnome 3 under Wayland. Both the Debian and Arch wikis note that KDE is buggy on Wayland. Gnome is the only desktop environment that supports it then, unless I want to go with Sway. There’s some appeal to Sway to this xmonad user, but I’ve read of incompatibilities of Wayland software when Gnome’s not available, so I opted to try Gnome.

Well, it’s better. Not perfect, but better. After finding settings buried in a ton of different Settings and Tweaks boxes, I had it mostly working, except gdm3 would never shut off power to the external display. Eventually I found /etc/gdm3/greeter.dconf-defaults, and aadded:

sleep-inactive-ac-timeout=60
sleep-inactive-ac-type='blank'
sleep-inactive-battery-timeout=120
sleep-inactive-battery-type='suspend'

Of course, these overlap with but are distinct from the same kinds of things in Gnome settings.

Sway?

Running without Gnome seems like a challenge; Gnome is switching audio output appropriately, for instance. I am looking at some of the Gnome Shell tiling window manager extensions and hope that some of them may work for me.

Excellent Experience with Debian Bullseye

I’ve appreciated the bullseye upgrade, like most Debian upgrades. I’m not quite sure how, since I was already running a backports kernel, but somehow the entire system is snappier. Maybe newer X or something? I’m really pleased with it. Hardware integration is even nicer now, particularly the automatic driverless support for scanners in addition to the existing support for printers.

All in all, a very nice upgrade, and pretty painless.

I experienced a few odd situations.

For one, I had been using Gnome Flashback. Since xmonad-log-applet didn’t compile there (due to bitrot in the log applet, not flashback), and I had been finding Gnome Flashback to be a rather dusty and forgotten corner of Gnome for a long time, I decided to try Mate.

Mate just seemed utterly unable to handle a situation with a laptop and an external monitor very well. I want to use only the external monitor with the laptop lid is closed, and it just couldn’t remember how to do the right thing – external monitor on, laptop monitor off, laptop not put into suspend. gdm3 also didn’t seem to be able to put the external monitor to sleep, either, causing a few nights of wasted power.

So off I went to XFCE, which I had been using for years on my workstation anyhow. Lots more settings available in XFCE, plus things Just Worked there. Odd that XFCE, the thin and light DE, is now the one that has the most relevant settings. It seems the Gnome “let’s remove a bunch of features” approach has extended to MATE as well.

When I switched to XFCE, I also removed gdm3 from my system, leaving lightdm as the only DM on it. That matched what my desktop machine was using, and also what task-xfce-desktop called for. But strangely, the XFCE settings for lightdm were completely different between the laptop and the desktop. It turns out that with lightdm, you can have the lightdm-gtk-greeter and the accompanying lightdm-gtk-greeter-settings, or slick-greeter and the accompanying lightdm-settings. One machine had one greeter and settings, and the other had the other. Why, I don’t know. But lightdm-gtk-greeter-settings had the necessary options for putting monitors to sleep on the login screen, so I went with it.

This does highlight a bit of a weakness in Debian upgrades. There is SO MUCH choice in Debian, which I highly value. At some point, almost certainly without my conscious choice, one machine got one greeter and another got the other. Despite both having task-xfce-desktop installed, they got different desktop experiences. There isn’t a great way to say “OK, I know I had a bunch of things installed before, but NOW I want the default bullseye experience”.

But overall, it is an absolutely fantastic distribution. It is great to see this nonprofit community distribution continue to have such quality on such an immense scale. And hard to believe I’ve been a Debian developer for 25 years. That seems almost impossible!

Remote Directory Tree Comparison, Optionally Asynchronous and Airgapped

Note: this is another article in my series on asynchronous communication in Linux with UUCP and NNCP.

In the previous installment on store-and-forward backups, I mentioned how easy it is to do with ZFS, and some of the tools that can be used to do it without ZFS. A lot of those tools are a bit less robust, so we need some sort of store-and-forward mechanism to verify backups. To be sure, verifying backups is good with ANY scheme, and this could be used with ZFS backups also.

So let’s say you have a shiny new backup scheme in place, and you’d like to verify that it’s working correctly. To do that, you need to compare the source directory tree on machine A with the backed-up directory tree on machine B.

Assuming a conventional setup, here are some ways you might consider to do that:

  • Just copy everything from machine A to machine B and compare locally
  • Or copy everything from machine A to a USB drive, plug that into machine B, and compare locally
  • Use rsync in dry-run mode and see if it complains about anything

The first two options are not particularly practical for large datasets, though I note that the second is compatible with airgapping. Using rsync requires both systems to be online at the same time to perform the comparison.

What would be really nice here is a tool that would write out lots of information about the files on a system: their names, sizes, last modified dates, maybe even sha256sum and other data. This file would be far smaller than the directory tree itself, would compress nicely, and could be easily shipped to an airgapped system via NNCP, UUCP, a USB drive, or something similar.

Tool choices

It turns out there are already quite a few tools in Debian (and other Free operating systems) to do this, and half of them are named mtree (though, of course, not all mtrees are compatible with each other.) We’ll look at some of the options here.

I’ve made a simple test directory for illustration purposes with these commands:

mkdir test
cd test
echo hi > hi
ln -s hi there
ln hi foo
touch empty
mkdir emptydir
mkdir somethingdir
cd somethingdir
ln -s ../there

I then also used touch to set all files to a consistent timestamp for illustration purposes.

Tool option: getfacl (Debian package: acl)

This comes with the acl package, but can be used with other than ACL purposes. Unfortunately, it doesn’t come with a tool to directly compare its output with a filesystem (setfacl, for instance, can apply the permissions listed but won’t compare.) It ignores symlinks and doesn’t show sizes or dates, so is ineffective for our purposes.

Example output:

$ getfacl --numeric -R test
...
# file: test/hi
# owner: 1000
# group: 1000
user::rw-
group::r--
other::r--
...

Tool option: fmtree, the FreeBSD mtree (Debian package: freebsd-buildutils)

fmtree can prepare a “specification” based on a directory tree, and compare a directory tree to that specification. The comparison also is aware of files that exist in a directory tree but not in the specification. The specification format is a bit on the odd side, but works well enough with fmtree. Here’s a sample output with defaults:

$ fmtree -c -p test
...
# .
/set type=file uid=1000 gid=1000 mode=0644 nlink=1
.               type=dir mode=0755 nlink=4 time=1610421833.000000000
    empty       size=0 time=1610421833.000000000
    foo         nlink=2 size=3 time=1610421833.000000000
    hi          nlink=2 size=3 time=1610421833.000000000
    there       type=link mode=0777 time=1610421833.000000000 link=hi

... skipping ...

# ./somethingdir
/set type=file uid=1000 gid=1000 mode=0777 nlink=1
somethingdir    type=dir mode=0755 nlink=2 time=1610421833.000000000
    there       type=link time=1610421833.000000000 link=../there
# ./somethingdir
..

..

You might be wondering here what it does about special characters, and the answer is that it has octal escapes, so it is 8-bit clean.

To compare, you can save the output of fmtree to a file, then run like this:

cd test
fmtree < ../test.fmtree

If there is no output, then the trees are identical. Change something and you get a line of of output explaining each difference. You can also use fmtree -U to change things like modification dates to match the specification.

fmtree also supports quite a few optional keywords you can add with -K. They include things like file flags, user/group names, various tipes of hashes, and so forth. I'll note that none of the options can let you determine which files are hardlinked together.

Here's an excerpt with -K sha256digest added:

    empty       size=0 time=1610421833.000000000 \
                sha256digest=e3b0c44298fc1c149afbf4c8996fb92427ae41e4649b934ca495991b7852b855
    foo         nlink=2 size=3 time=1610421833.000000000 \
                sha256digest=98ea6e4f216f2fb4b69fff9b3a44842c38686ca685f3f55dc48c5d3fb1107be4

If you include a sha256digest in the spec, then when you verify it with fmtree, the verification will also include the sha256digest. Obviously fmtree -U can't correct a mismatch there, but of course it will detect and report it.

Tool option: mtree, the NetBSD mtree (Debian package: mtree-netbsd)

mtree produces (by default) output very similar to fmtree. With minor differences (such as the name of the sha256digest in the output), the discussion above about fmtree also applies to mtree.

There are some differences, and the most notable is that mtree adds a -C option which reads a spec and converts it to a "format that's easier to parse with various tools." Here's an example:

$ mtree -c -K sha256digest -p test | mtree -C
. type=dir uid=1000 gid=1000 mode=0755 nlink=4 time=1610421833.0 flags=none
./empty type=file uid=1000 gid=1000 mode=0644 nlink=1 size=0 time=1610421833.0 flags=none
./foo type=file uid=1000 gid=1000 mode=0644 nlink=2 size=3 time=1610421833.0 flags=none
./hi type=file uid=1000 gid=1000 mode=0644 nlink=2 size=3 time=1610421833.0 flags=none
./there type=link uid=1000 gid=1000 mode=0777 nlink=1 link=hi time=1610421833.0 flags=none
./emptydir type=dir uid=1000 gid=1000 mode=0755 nlink=2 time=1610421833.0 flags=none
./somethingdir type=dir uid=1000 gid=1000 mode=0755 nlink=2 time=1610421833.0 flags=none
./somethingdir/there type=link uid=1000 gid=1000 mode=0777 nlink=1 link=../there time=1610421833.0 flags=none

Most definitely an improvement in both space and convenience, while still retaining the relevant information. Note that if you want the sha256digest in the formatted output, you need to pass the -K to both mtree invocations. I could have done that here, but it is easier to read without it.

mtree can verify a specification in either format. Given what I'm about to show you about bsdtar, this should illustrate why I bothered to package mtree-netbsd for Debian.

Unlike fmtree, the mtree -U command will not adjust modification times based on the spec, but it will report on differences.

Tool option: bsdtar (Debian package: libarchive-tools)

bsdtar is a fascinating program that can work with many formats other than just tar files. Among the formats it supports is is the NetBSD mtree "pleasant" format (mtree -C compatible).

bsdtar can also convert between the formats it supports. So, put this together: bsdtar can convert a tar file to an mtree specification without extracting the tar file. bsdtar can also use an mtree specification to override the permissions on files going into tar -c, so it is a way to prepare a tar file with things owned by root without resorting to tools like fakeroot.

Let's look at how this can work:

$ cd test
$ bsdtar --numeric -cf - --format=mtree .

. time=1610472086.318593729 mode=755 gid=1000 uid=1000 type=dir
./empty time=1610421833.0 mode=644 gid=1000 uid=1000 type=file size=0
./foo nlink=2 time=1610421833.0 mode=644 gid=1000 uid=1000 type=file size=3
./hi nlink=2 time=1610421833.0 mode=644 gid=1000 uid=1000 type=file size=3
./ormat\075mtree time=1610472086.318593729 mode=644 gid=1000 uid=1000 type=file size=5632
./there time=1610421833.0 mode=777 gid=1000 uid=1000 type=link link=hi
./emptydir time=1610421833.0 mode=755 gid=1000 uid=1000 type=dir
./somethingdir time=1610421833.0 mode=755 gid=1000 uid=1000 type=dir
./somethingdir/there time=1610421833.0 mode=777 gid=1000 uid=1000 type=link link=../there

You can use mtree -U to verify that as before. With the --options mtree: set, you can also add hashes and similar to the bsdtar output. Since bsdtar can use input from tar, pax, cpio, zip, iso9660, 7z, etc., this capability can be used to create verification of the files inside quite a few different formats. You can convert with bsdtar -cf output.mtree --format=mtree @input.tar. There are some foibles with directly using these converted files with mtree -U, but usually minor changes will get it there.

Side mention: stat(1) (Debian package: coreutils)

This tool isn't included because it won't operate recursively, but is a tool in the similar toolbox.

Putting It Together

I will still be developing a complete non-ZFS backup system for NNCP (or UUCP) in a future post. But in the meantime, here are some ideas you can reflect on:

  • Let's say your backup scheme involves sending a full backup every night. On the source system, you could pipe the generated tar file through something like tee >(bsdtar -cf bcakup.mtree @-) to generate an mtree file in-band while generating the tar file. This mtree file could be shipped over for verification.
  • Perhaps your backup scheme involves sending incremental backup data via rdup or even ZFS, but you would like to periodically verify that everything is good -- that an incremental didn't miss something. Something like mtree -K sha256 -c -x -p / | mtree -C -K sha256 would let you accomplish that.

I will further develop at least one of these ideas in a future post.

Bonus: cross-tool comparisons

In my mtree-netbsd packaging, I added tests like this to compare between tools:

fmtree -c -K $(MTREE_KEYWORDS) | mtree
mtree -c -K $(MTREE_KEYWORDS) | sed -e 's/\(md5\|sha1\|sha256\|sha384\|sha512\)=/\1digest=/' -e 's/rmd160=/ripemd160digest=/' | fmtree
bsdtar -cf - --options 'mtree:uname,gname,md5,sha1,sha256,sha384,sha512,device,flags,gid,link,mode,nlink,size,time,uid,type,uname' --format mtree . | mtree

Airgapped / Asynchronous Backups with ZFS over NNCP

In my previous articles in the series on asynchronous communication with the modern NNCP tool, I talked about its use for asynchronous, potentially airgapped, backups. The first article, How & Why To Use Airgapped Backups laid out the foundations for this. Now let’s dig into the details.

Today’s post will cover ZFS, because it has a lot of features that make it very easy to support in this setup. Non-ZFS backups will be covered later.

The setup is actually about as simple as it is for SSH, but since people are less familiar with this kind of communication, I’m going to try to go into more detail here.

Assumptions

I am assuming a setup where:

  • The machines being backed up run ZFS
  • The disk(s) that hold the backups are also running ZFS
  • zfs send / receive is desired as an efficient way to transport the backups
  • The machine that holds the backups may have no network connection whatsoever
  • Backups will be sent encrypted over some sort of network to a spooling machine, which temporarily holds them until they are transported to the destination backup system and ingested there. This system will be unable to decrypt the data streams it temporarily stores.

Hardware

Let’s start with hardware for the machine to hold the backups. I initially considered a Raspberry Pi 4 with 8GB of RAM. That would probably have been a suitable machine, at least for smaller backup sets. However, none of the Raspberry Pi machines support hardware AES encryption acceleration, and my Pi4 benchmarks as about 60MB/s for AES encryption. I want my backups to be encrypted, and decided this would just be too slow for my purposes. Again, if you don’t need encrypted backups or don’t care that much about performance — may people probably fall into this category — you can have a fully-functional Raspberry Pi 4 system for under $100 that would make a fantastic backup server.

I wound up purchasing a Qotom-Q355G4 micro PC with a Core i5 for about $315. It has USB 3 ports and is designed as a rugged, long-lasting system. I have been using one of their older Celeron-based models as my router/firewall for a number of years now and it’s been quite reliable.

For backup storage, you can get a USB 3 external drive. My own preference is to get a USB 3 “toaster” (device that lets me plug in SATA drives) so that I have more control over the underlying medium and can save the expense and hassle of a bunch of power supplies. In a future post, I will discuss drive rotation so you always have an offline drive.

Then, there is the question of transport to the backup machine. A simple solution would be to have a heavily-firewalled backup system that has no incoming ports open but makes occasional outgoing connections to one specific NNCP daemon on the spooling machine. However, for airgapped operation, it would also be very simple to use nncp-xfer to transport the data across on a USB stick or some such. You could set up automounting for a specific USB stick – plug it in, all the spooled data is moved over, then plug it in to the backup system and it’s processed, and any outbound email traffic or whatever is copied to the USB stick at that point too. The NNCP page has some more commentary about this kind of setup.

Both are fairly easy to set up, and NNCP is designed to be transport-agnostic, so in this article I’m going to focus on how to integrate ZFS with NNCP.

Operating System

Of course, it should be no surprise that I set this up on Debian.

As an added step, I did all the configuration in Ansible stored in a local git repo. This adds a lot of work, but it means that it is trivial to periodically wipe and reinstall if any security issue is suspected. The git repo can be copied off to another system for storage and takes the system from freshly-installed to ready-to-use state.

Security

There is, of course, nothing preventing you from running NNCP as root. The zfs commands, obviously, need to be run as root. However, from a privilege separation standpoint, I have chosen to run everything relating to NNCP as a nncp user. NNCP already does encryption, but if you prefer to have zero knowledge of the data even to NNCP, it’s trivial to add gpg to the pipeline as well, and in fact I’ll be demonstrating that in a future post for other reasons.

Software

Besides NNCP, there needs to be a system that generates the zfs send streams. For this project, I looked at quite a few. Most were designed to inspect the list of snapshots on a remote end, compare it to a list on the local end, and calculate a difference from there. This, of course, won’t work for this situation.

I realized my own simplesnap project was very close to being able to do this. It already used an algorithm of using specially-named snapshots on the machine being backed up, so never needed any communication about what snapshots were present where. All it needed was a few more options to permit sending to a stream instead of zfs receive. I made those changes and they are available in simplesnap 2.0.0 or above. That version has also been uploaded to sid, and will work fine as-is on buster as well.

Preparing NNCP

I’m going to assume three hosts in this setup:

  • laptop is the machine being backed up. Of course, you may have quite a few of these.
  • spooler holds the backup data until the backup system picks it up
  • backupsvr holds the backups

The basic NNCP workflow documentation covers the basic steps. You’ll need to run nncp-cfgnew on each machine. This generates a basic configuration, along with public and private keys for that machine. You’ll copy the public key sets to the configurations of the other machines as usual. On the laptop, you’ll add a via line like this:

backupsvr: {
  id: ....
  exchpub: ...
  signpub: ...
  noisepub: ...
  via: ["spooler"]

This tells NNCP that data destined for backupsvr should always be sent via spooler first.

You can then arrange for the nncp-daemon to run on the spooler, and nncp-caller or nncp-call on the backupsvr. Or, alternatively, airgapped between the two with nncp-xfer.

Generating Backup Data

Now, on the laptop, install simplesnap (2.0.0 or above). Although you won’t be backing up to the local system, simplesnap still maintains a hostlock in ZFS. Prepate a dataset for it:

zfs create tank/simplesnap
zfs set org.complete.simplesnap:exclude=on tank/simplesnap

Then, create a script /usr/local/bin/runsimplesnap like this:

#!/bin/bash

set -e

simplesnap --store tank/simplesnap --setname backups --local --host `hostname` \
   --receivecmd /usr/local/bin/simplesnap-queue \
   --noreap

su nncp -c '/usr/local/nncp/bin/nncp-toss -noprogress -quiet'

if ip addr | grep -q 192.168.65.64; then
  su nncp -c '/usr/local/nncp/bin/nncp-call -noprogress -quiet -onlinedeadline 1 spooler'
fi

The call to simplesnap sets it up to send the data to simplesnap-queue, which we’ll create in a moment. The –receivmd, plus –noreap, sets it up to run without ZFS on the local system.

The call to nncp-toss will process any previously-received inbound NNCP packets, if there are any. Then, in this example, we do a very basic check to see if we’re on the LAN (checking 192.168.65.64), and if so, will establish a connection to the spooler to transmit the data. If course, you could also do this over the Internet, with tor, or whatever, but in my case, I don’t want to automatically do this in case I’m tethered to mobile. I figure if I want to send backups in that case, I can fire up nncp-call myself. You can also use nncp-caller to set up automated connections on other schedules; there are a lot of options.

Now, here’s what /usr/local/bin/simplesnap-queue looks like:

#!/bin/bash

set -e
set -o pipefail

DEST="`echo $1 | sed 's,^tank/simplesnap/,,'`"

echo "Processing $DEST" >&2
# stdin piped to this
su nncp -c "/usr/local/nncp/bin/nncp-exec -nice B -noprogress backupsvr zfsreceive '$DEST'" >&2
echo "Queued for $DEST" >&2

This is a pretty simple script. simplesnap will call it with a path based on the –store, with the hostname after; so, for instance, tank/simplesnap/laptop/root or some such. This script strips off the leading tank/simplesnap (which is a local fragment), leaving the host and dataset paths. Then it just pipes it to nncp-exec. -nice B classifies it as low-priority bulk data (so if you have some more important interactive data, it would be sent first), then passes it to whatever the backupsvr defines as zfsreceive.

Receiving ZFS backups

In the NNCP configuration on the recipient’s side, in the laptop section, we define what command it’s allowed to run as zfsreceive:

      exec: {
        zfsreceive: ["/usr/bin/sudo", "-H", "/usr/local/bin/nncp-zfs-receive"]
      }

We authorize the nncp user to run this under sudo in /etc/sudoers.d/local–nncp:

Defaults env_keep += "NNCP_SENDER"
nncp ALL=(root) NOPASSWD: /usr/local/bin/nncp-zfs-receive

The NNCP_SENDER is the public key ID of the sending node when nncp-toss processes the incoming data. We can use that for sanity checking later.

Now, here’s a basic nncp-zfs-receive script:

#!/bin/bash
set -e
set -o pipefail

STORE=backups/simplesnap
DEST="$1"

# now process stdin
runcommand zfs receive -o readonly=on -x mountpoint "$STORE/$DEST"

And there you have it — all the basics are in place.

Update 2020-12-30: An earlier version of this article had “zfs receive -F” instead of “zfs receive -o readonly=on -x mountpoint”. These changed arguments are more robust.
Update 2021-01-04: I am now recommending “zfs receive -u -o readonly=on”; see my successor article for more.

Enhancements

You could enhance the nncp-zfs-receive script to improve logging and error handling. For instance:

#!/bin/bash

set -e
set -o pipefail

STORE=backups/simplesnap
# $1 will be the host/dataset

DEST="$1"
HOST="`echo "$1" | sed 's,/.*,,g'`"
if [ -z "$HOST" ]; then
   echo "Malformed command line"
   exit 5
fi

# Log a message
logit () {
   logger -p info -t "`basename "$0"`[$$]" "$1"
}

# Log an error message
logerror () {
   logger -p err -t "`basename "$0"`[$$]" "$1"
}

# Log stdin with the given code.  Used normally to log stderr.
logstdin () {
   logger -p info -t "`basename "$0"`[$$/$1]"
}

# Run command, logging stderr and exit code
runcommand () {
   logit "Running $*"
   if "$@" 2> >(logstdin "$1") ; then
      logit "$1 exited successfully"
      return 0
   else
       RETVAL="$?"
       logerror "$1 exited with error $RETVAL"
       return "$RETVAL"
   fi
}
exiterror () {
   logerror "$1"
   echo "$1" 1>&2
   exit 10
}

# Sanity check

if [ "$HOST" = "laptop" ]; then
  if [ "$NNCP_SENDER" != "12345678" ]; then
    exiterror "Host $HOST doesn't match sender $NNCP_SENDER"
  fi
else
  exiterror "Unknown host $HOST"
fi

runcommand zfs receive -F "$STORE/$DEST"

Now you’ll capture the ZFS receive output in syslog in a friendly way, so you can look back later why things failed if they did.

Further notes on NNCP

nncp-toss will examine the exit code from an invocation. If it is nonzero, it will keep the command (and associated stdin) in the queue and retry it on the next invocation. NNCP does not guarantee order of execution, so it is possible in some cases that ZFS streams may be received in the wrong order. That is fine here; zfs receive will exit with an error, and nncp-toss will just run it again after the dependent snapshots have been received. For non-ZFS backups, a simple sequence number can handle this issue.

Long-Range Radios: A Perfect Match for Unix Protocols From The 70s

It seems I’ve been on a bit of a vintage computing kick lately. After connecting an original DEC vt420 to Linux and resurrecting some old operating systems, I dove into UUCP.

In fact, it so happened that earlier in the week, my used copy of Managing UUCP & Usenet (its author list includes none other than Tim O’Reilly) arrived. I was reading about the challenges of networking in the 70s: half-duplex lines, slow transmission rates, and modems that had separate dialers. And then I stumbled upon long-distance radio. It turns out that a lot of modern long-distance radio has much in common with the challenges of communication in the 1970s – 1990s, and some of our old protocols might be particularly well-suited for it. Let me explain — I’ll start with the old software, and then talk about the really cool stuff going on in hardware (some radios that can send a signal for 10-20km or more with very little power!), and finally discuss how to bring it all together.

UUCP

UUCP, for those of you that may literally have been born after it faded in popularity, is a batch system for exchanging files and doing remote execution. For users, the uucp command copies files to or from a remote system, and uux executes commands on a remote system. In practical terms, the most popular use of this was to use uux to execute rmail on the remote system, which would receive an email message on stdin and inject it into the system’s mail queue. All UUCP commands are queued up and transmitted when a “call” occurs — over a modem, TCP, ssh pipe, whatever.

UUCP had to deal with all sorts of line conditions: very slow lines (300bps), half-duplex lines, noisy and error-prone communication, poor or nonexistent flow control, even 7-bit communication. It supports a number of different transport protocols that can accommodate these varying conditions. It turns out that these mesh fairly perfectly with some properties of modern long-distance radio.

AX.25

The AX.25 stack is a frame-based protocol used by amateur radio folks. Its air speed is 300bps, 1200bps, or (rarely) 9600bps. The Linux kernel has support for the AX.25 protocol and it is quite possible to run TCP/IP atop it. I have personally used AX.25 to telnet to a Linux box 15 miles away over a 1200bps air speed, and have also connected all the way from Kansas to Texas and Indiana using 300bps AX.25 using atmospheric skip. AX.25 has “connected” packets (as TCP) and unconnected/broadcast ones (similar to UDP) and is a error-detected protocol with retransmit. The radios generally used with AX.25 are always half-duplex and some of them have iffy carrier detection (which means collision is frequent). Although the whole AX.25 stack has grown rare in recent years, a subset of it is still in wide use as the basis for APRS.

A lot of this is achieved using equipment that’s not particularly portable: antennas on poles, radios that transmit with anywhere from 1W to 100W of power (even 1W is far more than small portable devices normally use), etc. Also, under the regulations of the amateur radio service, transmitters must be managed by a licensed operator and cannot be encrypted.

Nevertheless, AX.25 is just a protocol and it could, of course, run on other kinds of carriers than traditional amateur radios.

Long-range low-power radios

There is a lot being done with radios these days, much of which I’m not going to discuss. I’m not covering very short-range links such as Bluetooth, ZigBee, etc. Nor am I covering longer-range links that require large and highly-directional antennas (such as some are doing in the 2.4GHz and 5GHz bands). What I’m covering is long-range links that can be used by portable devices.

There is always a compromise in radios, and if we are going to achieve long-range links with poor antennas and low power, the compromise is going to be in bitrate. These technologies may scale down to as low at 300bps or up to around 115200bps. They can, as a side bonus, often be quite cheap.

HC-12 radios

HC-12 is a radio board, commonly used with Arduino, that sports 500bps to 115200bps communication. According to the vendor, in 500bps mode, the range is 1800m or 0.9mi, while at 115200bps, the range is 100m or 328ft. They’re very cheap, at around $5 each.

There are a few downsides to HC-12. One is that the lowest air bitrate is 500bps, but the lowest UART bitrate is 1200bps, and they have no flow control. So, if you are running in long-range mode, “only small packets can be sent: max 60 bytes with the interval of 2 seconds.” This would pose a challenge in many scenarios: though not much for UUCP, which can be perfectly well configured to have a 60-byte packet size and a window size of 1, which would wait for a remote ACK before proceeding.

Also, they operate over 433.4-473.0 MHz which appears to fall outside the license-free bands. It seems that many people using HC-12 are doing so illegally. With care, it would be possible to operate it under amateur radio rules, since this range is mostly within the 70cm allocation, but then it must follow amateur radio restrictions.

LoRa radios

LoRa is a set of standards for long range radios, which are advertised as having a range of 15km (9mi) or more in rural areas, and several km in cities.

LoRa can be done in several ways: the main LoRa protocol, and LoRaWAN. LoRaWAN expects to use an Internet gateway, which will tell each node what frequency to use, how much power to use, etc. LoRa is such that a commercial operator could set up roughly one LoRaWAN gateway per city due to the large coverage area, and some areas have good LoRa coverage due to just such operators. The difference between the two is roughly analogous to the difference between connecting two machines with an Ethernet crossover cable, and a connection over the Internet; LoRaWAN includes more protocol layers atop the basic LoRa. I have yet to learn much about LoRaWAN; I’ll follow up later on that point.

The speed of LoRa ranges from (and different people will say different things here) about 500bps to about 20000bps. LoRa is a packetized protocol, and the maximum packet size depends

LoRa sensors often advertise battery life in the months or years, and can be quite small. The protocol makes an excellent choice for sensors in remote or widely dispersed areas. LoRa transceiver boards for Arduino can be found for under $15 from places like Mouser.

I wound up purchasing two LoStik USB LoRa radios from Amazon. With some experimentation, with even very bad RF conditions (tiny antennas, one of them in the house, the other in a car), I was able to successfully decode LoRa packets from 2 miles away! And these aren’t even the most powerful transmitters available.

Talking UUCP over LoRa

In order to make this all work, I needed to write interface software; the LoRa radios don’t just transmit things straight out. So I wrote lorapipe. I have successfully transmitted files across this UUCP link!

Developing lorapipe was somewhat more challenging than I expected. For one, the LoRa modem raw protocol isn’t well-suited to rapid fire packet transmission; after receiving each packet, the modem exits receive mode and must be told to receive again. Collisions with protocols that ACKd data and had a receive window — which are many — were a problem so bad that it rendered some of the protocols unusable. I wound up adding a “expect more data after this packet” byte to every transmission, and have the receiver not transmit until it believes the sender is finished. This dramatically improved things. There’s more detail on this in my lorapipe documentation.

So far, I have successfully communicated over LoRa using UUCP, kermit, and YMODEM. KISS support will be coming next.

I am also hoping to discover the range I can get from this thing if I use more proper antennas (outdoor) and transmitters capable of transmitting with more power.

All in all, a fun project so far.

Connecting A Physical DEC vt420 to Linux

John and Oliver trip to Vintage Computer Festival Midwest 2019. Oliver playing Zork on the Micro PDP-11

Inspired by a weekend visit to Vintage Computer Festival Midwest at which my son got to play Zork on an amber console hooked up to a MicroPDP-11 running 2BSD, I decided it was time to act on my long-held plan to get a real old serial console hooked up to Linux.

Not being satisfied with just doing it for the kicks, I wanted to make it actually usable. 30-year-old DEC hardware meets Raspberry Pi. I thought this would be pretty easy, but it turns out is was a lot more complicated than I realized, involving everything from nonstandard serial connectors to long-standing kernel bugs!

Selecting a Terminal — And Finding Parts

I wanted something in amber for that old-school feel. Sadly I didn’t have the forethought to save any back in the 90s when they were all being thrown out, because now they’re rare and can be expensive. Search eBay and pretty soon you find a scattering of DEC terminals, the odd Bull or Honeywell, some Sperrys, and assorted oddballs that don’t speak any kind of standard protocol. I figured, might as well get a vt, since we’re still all emulating them now, 40+ years later. Plus, my old boss from my university days always had stories about DEC. I wish he were still around to see this.

I selected the vt420 because I was able to find them, and it has several options for font size, letting more than 24 lines fit on a screen.

Now comes the challenge: most of the vt420s never had a DB25 RS-232 port. The VT420-J, an apparently-rare international model, did, but it is exceptionally rare. The rest use a DEC-specific port called the MMJ. Thankfully, it is electrically compatible with RS-232, and I managed to find the DEC H8571-J adapter as well as a BC16E MMJ cable that I need.

I also found a vt510 (with “paperwhite” instead of amber) in unknown condition. I purchased it, and thankfully it is also working. The vt510 is an interesting device; for that model, they switched to using a PS/2 keyboard connector, and it can accept either a DEC VT keyboard or a PC keyboard. It also supports full key remapping, so Control can be left of A as nature intended. However, there’s something about amber that is just so amazing to use again.

Preparing the Linux System

I thought I would use a Raspberry Pi as a gateway for this. With built-in wifi, that would let me ssh to other machines in my house without needing to plug in a serial cable – I could put the terminal wherever. Alternatively, I can plug in a USB-to-serial adapter to my laptop and just plug the terminal into it when I want. I wound up with a Raspberry Pi 4 kit that included some heatsinks.

I had two USB-to-serial adapters laying around: a Keyspan USA-19HS and a Digi I/O Edgeport/1. I started with the Keyspan on a Raspberry Pi 4 on the grounds that I didn’t have the needed Edgeport/1 firmware file laying about already. The Raspberry Pi does have serial capability integrated, but it doesn’t use RS-232 voltages and there have been reports of it dropping characters sometimes, so I figured the easy path would be a USB adapter. That turned out to be only partially right.

Serial Terminals with systemd

I have never set up a serial getty with systemd — it has, in fact, been quite a long while since I’ve done anything involving serial other than the occasional serial console (which is a bit different purpose).

It would have taken a LONG time to figure this out, but thanks to an article about the topic, it was actually pretty easy in the end. I didn’t set it up as a serial console, but spawning a serial getty did the trick. I wound up modifying the command like this:

ExecStart=-/sbin/agetty -8 -o '-p -- \\u' %I 19200 vt420

The vt420 supports speeds up to 38400 and the vt510 supports up to 115200bps. However, neither can process plain text at faster than 19200 so there is no point to higher speeds. And, as you are about to see, they can’t necessarily even muster 19200 all the time.

Flow Control: Oh My

The unfortunate reality with these old terminals is that the processor in them isn’t actually able to keep up with line speeds. Any speed above 4800bps can exceed processor capabilities when “expensive” escape sequences are sent. That means that proper flow control is a must. Unfortunately, the vt420 doesn’t support any form of hardware flow control. XON/XOFF is all it’ll do. Yeah, that stinks.

So I hooked the thing up to my desktop PC with a null-modem cable, and started to tinker. I should be able to send a Ctrl-S down the line and the output from the pi should immediately stop. It didn’t. Huh. I verified it was indeed seeing the Ctrl-S (open emacs, send Ctrl-S, and it goes into search mode). So something, somehow, was interfering.

After a considerable amount of head scratching, I finally busted out the kernel source. I discovered that the XON/XOFF support is part of the serial driver in Linux, and that — ugh — the keyspan serial driver never actually got around to implementing it. Oops. That’s a wee bit of a bug. I plugged in the Edgeport/1 instead of the Keyspan and magically XON/XOFF started working.

Well, for a bit.

You see, flow control is a property of the terminal that can be altered by programs on a running system. It turns out that a lot of programs have opinions about it, and those opinions generally run along the lines of “nobody could possibly be using XON/XOFF, so I’m going to turn it off.” Emacs is an offender here, but it can be configured. Unfortunately, the most nasty offender here is ssh, which contains this code that is ALWAYS run when using a pty to connect to a remote system (which is for every interactive session):

tio.c_iflag &= ~(ISTRIP | INLCR | IGNCR | ICRNL | IXON | IXANY | IXOFF);

Yes, so when you use ssh, your local terminal no longer does flow control. If you are particularly lucky, the remote end may recognize your XON/XOFF characters and process them. Unfortunately, the added latency and buffering in going through ssh and the network is likely to cause bursts of text to exceed the vt420’s measly 100-ish-byte buffer. You just can’t let the remote end handle flow control with ssh. I managed to solve this via GNU Screen; more on that later.

The vt510 supports hardware flow control! Unfortunately, it doesn’t use CTS/RTS pins, but rather DTR/DSR. This was a reasonably common method in the day, but appears to be totally unsupported in Linux. Bother. I see some mentions that FreeBSD supports DTR/DSR flow (dtrflow and dsrflow in stty outputs). It definitely looks like the Linux kernel has never plumbed out the reaches of RS-232 very well. It should be possible to build a cable to swap DTR/DSR over to CTS/RTS, but since the vt420 doesn’t support any of this anyhow, I haven’t bothered.

Character Sets

Back when the vt420 was made, it was pretty hot stuff that it was one of the first systems to support the new ISO-8859-1 standard. DEC was rather proud of this. It goes without saying that the terminal knows nothing of UTF-8.

Nowadays, of course, we live in a Unicode world. A lot of software crashes on ISO-8859-1 input (I’m looking at you, Python 3). Although I have old files from old systems that have ISO-8859-1 encoding, they are few and far between, and UTF-8 rules the roost now.

I can, of course, just set LANG=en_US and that will do — well, something. man, for instance, renders using ISO-8859-1 characters. But that setting doesn’t imply that any layer of the tty system actually converts output from UTF-8 to ISO-8859-1. For instance, if I have a file with a German character in it and use ls, nothing is going to convert it from UTF-8 to ISO-8859-1.

GNU Screen also, as it happens, mostly solves this.

GNU Screen to the rescue, somewhat

It turns out that GNU Screen has features that can address both of these issues. Here’s how I used it.

First, in my .bashrc, I set this:


if [ `tty` = "/dev/ttyUSB0" ]; then
stty -iutf8
export LANG=en_US
export MANOPT="-E ascii"
fi

Then, in my .screenrc, I put this:


defflow on
defencoding UTF-8

This tells screen that the default flow control mode is on, and that the default encoding for the pty that screen creates is UTF-8. It determines the encoding for the physical terminal for the environment, and correctly figures it to be ISO-8859-1. It then maps between the two! Yes!

My little ssh connecting script then does just this:

exec screen ssh "$@"

Which nicely takes care of the flow control issue and (most of) the encoding issue. I say “most” because now things like man will try to render with fancy em-dashes and the like, which have no representation in iso8859-1, so they come out as question marks. (Setting MANOPT=”-E ascii” fixes this) But no matter, it works to ssh to my workstation and read my email! (mu4e in emacs)

What screen doesn’t help with are things that have no ISO-8859-1 versions; em-dashes are the most frequent problems, and are replaced with unsightly question marks.

termcaps, terminfos, and weird things

So pretty soon you start diving down the terminal rabbit hole, and you realize there’s a lot of weird stuff out there. For instance, one solution to the problem of slow processors in terminals was padding: ncurses would know how long it would take the terminal to execute some commands, and would send it NULLs for that amount of time. That calculation, of course, requires knowledge of line speed, which one wouldn’t have in this era of ssh. Thankfully the vt420 doesn’t fall into that category.

But it does have a ton of modes. The Emacs On Terminal page discusses some of the interesting bits: 7-bit or 8-bit control characters, no ESC key, Alt key not working, etc, etc. I believe some of these are addressed by the vt510 (at least in PC mode). I wonder whether Emacs or vim keybindings would be best here…

Helpful Resources
